Allen-Bradley Kinetix 5500 Design Guide

Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 81
Kinetix 5500 Drive Systems
LDAT-Series Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance Specifications with Frame 30 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 5500 Drives
(240V AC input)
LDAT-S031010-DDx 2.4
4.8 81 (18) 12.2 168 (38)
0.20
2198-H015-ERSx
LDAT-S031020-DDx 3.1 0.25
LDAT-S031030-DDx 3.5 0.29
LDAT-S031040-DDx 3.8 0.31
LDAT-S032010-DDx 3.1
7.4
126 (28)
24.3
336 (76)
0.44
2198-H025-ERSx
LDAT-S032020-DDx 4.1 0.52
LDAT-S032030-DDx 4.7 0.59
LDAT-S032040-DDx 5.0 0.63
LDAT-S032010-EDx 3.1
3.7 12.2
0.40
2198-H015-ERSx
LDAT-S032020-EDx 4.1 0.47
LDAT-S032030-EDx 4.7 0.52
LDAT-S032040-EDx 5.0 0.55
LDAT-S033010-DDx 3.5
11.1
190 (43)
36.5
504 (113)
0.67
2198-H040-ERSx
LDAT-S033020-DDx 4.7 0.88
LDAT-S033030-DD
x
5.0 0.95
LDAT-S033040-DDx
LDAT-S033010-EDx 3.5
3.7 12.2
0.55
2198-H015-ERSx
LDAT-S033020-EDx
4.4 0.65LDAT-S033030-EDx
LDAT-S033040-EDx
Performance Specifications with Frame 50 Linear Thruster
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 5500 Drives
(240V AC input)
LDAT-S051010-DDx 2.8
3.1 119 (27) 11.4 363 (82)
0.31
2198-H015-ERSx
LDAT-S051020-DDx 3.7 0.38
LDAT-S051030-DDx 4.1 0.42
LDAT-S051040-DDx 4.4 0.44
LDAT-S051050-DDx 4.7 0.46
LDAT-S052010-DDx 3.7
6.2
251 (56)
22.7
727 (163)
0.79
2198-H025-ERSx
LDAT-S052020-DDx 4.8 0.97
LDAT-S052030-DDx
5.00 1.01LDAT-S052040-DDx
LDAT-S052050-DDx
LDAT-S052010-EDx
…
LDAT-S052050-EDx
2.6 3.1 11.4 0.50 2198-H015-ERSx
