Allen-Bradley Kinetix 5500 Design Guide

Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 91
Kinetix 5500 Drive Systems
Performance Specifications with Frame 50 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5500 Drives
(480V AC input)
LDAT-S051010-DDx 2.8
3.1 119 (27) 11.4 363 (82)
0.34
2198-H015-ERSx
LDAT-S051020-DDx 3.7 0.43
LDAT-S051030-DDx 4.1 0.49
LDAT-S051040-DDx 4.4 0.53
LDAT-S051050-DDx 4.7 0.55
LDAT-S052010-DDx 3.7
6.2
251 (56)
22.7
727 (163)
0.92
2198-H025-ERSx
LDAT-S052020-DDx 4.8 1.20
LDAT-S052030-DDx
5.0 1.24LDAT-S052040-DDx
LDAT-S052050-DDx
LDAT-S052010-EDx 3.7
3.1 11.4
0.80
2198-H015-ERSx
LDAT-S052020-EDx 4.6 0.98
LDAT-S052030-EDx
4.6 1.02LDAT-S052040-EDx
LDAT-S052050-EDx
LDAT-S053010-DDx 4.1
9.4
378 (85)
34.2
1093 (246)
1.56
2198-H040-ERSx
LDAT-S053020-DD
x
5.0 1.87
LDAT-S053030-DDx
…
LDAT-S053050-DDx
LDAT-S053010-EDx
…
LDAT-S053050-EDx
3.5 3.1 11.4 1.04 2198-H015-ERSx
LDAT-S054010-DDx 4.4
12.4
509 (114)
45.5
1453 (327)
2.26
2198-H040-ERSx
LDAT-S054020-DDx
…
LDAT-S054050-DDx
5.00 2.53
LDAT-S054010-EDx 4.4
6.2 22.7
1.87
2198-H025-ERSx
LDAT-S054020-EDx
…
LDAT-S054050-EDx
5.0 2.05
