Allen-Bradley Kinetix 5500 Design Guide

Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 93
Kinetix 5500 Drive Systems
Performance Specifications with Frame 100 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5500 Drives
(480V AC input)
LDAT-S102010-DDx 3.4
5.7
456 (103)
21.0
1289 (290)
1.44
2198-H025-ERSx
LDAT-S102020-DDx 4.4 1.74
LDAT-S102030-DDx
5.0 1.91
LDAT-S102040-DDx
LDAT-S102050-DDx
…
LDAT-S102090-DDx
LDAT-S102010-EDx
…
LDAT-S102090-EDx
2.6 2.9 10.5 0.96 2198-H015-ERSx
LDAT-S103010-DDx 3.8
8.6
702 (158)
31.5
1935 (435)
2.41
2198-H040-ERSx
LDAT-S103020-DDx
5.0 2.93
LDAT-S103030-DDx
…
LDAT-S103090-DDx
LDAT-S103010-EDx
…
LDAT-S103090-EDx
1.8 2.9 10.5 0.92 2198-H015-ERSx
LDAT-S104010-DDx 4.1
11.5
929 (209)
42.0
2578 (580)
3.76
2198-H040-ERSx
LDAT-S104020-DDx
5.0 4.29
LDAT-S104030-DDx
…
LDAT-S104090-DD
x
LDAT-S104010-EDx
…
LDAT-S104090-EDx
2.7 5.7 21.0 2.07 2198-H025-ERSx
LDAT-S106010-DDx 4.5
17.3
1403 (315)
63.0
3871 (870)
5.41
2198-H070-ERSx
LDAT-S106020-DDx
…
LDAT-S106090-DDx
5.0 5.87
LDAT-S106010-EDx
…
LDAT-S106090-EDx
2.7 8.6 31.5 2.94 2198-H040-ERSx
