Process Control Instructions
176 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
CV2ProgInv BOOL CV2Prog < 0 or > 100, or <
CV2LLimit or > CV2HLimit when
CVManLimiting is TRUE. Limit value
used for CV2.
CV3ProgInv BOOL CV3Prog < 0 or > 100, or <
CV3LLimit or > CV3HLimit when
CVManLimiting is TRUE. Limit value
used for CV3.
CV1OperInv BOOL CV1Oper < 0 or > 100, or <
CV1LLimit or > CV1HLimit when
CVManLimiting is TRUE. Limit value
used for CV1.
CV2OperInv BOOL CV2Oper < 0 or > 100, or <
CV2LLimit or> CV2HLimit when
CVManLimiting is TRUE. Limit value
used for CV2.
CV3OperInv BOOL CV3Oper < 0 or > 100, or <
CV3LLimit or> CV3HLimit when
CVManLimiting is TRUE. Limit value
used for CV3.
CV1OverrideValueInv BOOL CV1OverrideValue < 0 or > 100.
Limit value used for CV1.
CV2OverrideValueInv BOOL CV2OverrideValue < 0 or > 100.
Limit value used for CV2.
CV3OverrideValueInv BOOL CV3OverrideValue < 0 or > 100.
Limit value used for CV3.
CV1TrackValueInv BOOL Entered CV1TrackValue < 0 or >
100. Limit value used for CV1.
CV2TrackValueInv BOOL Entered CV2TrackValue < 0 or >
100. Limit value used for CV2.
CV3TrackValueInv BOOL Entered CV3TrackValue < 0 or >
100. Limit value used for CV3.
CV1EUSpanInv BOOL The span of CV1EU inValid,
CV1EUMax equals CV1EUMin.
CV2EUSpanInv BOOL The span of CV2EU inValid,
CV2EUMax equals CV2EUMin.
CV3EUSpanInv BOOL The span of CV3EU inValid,
CV3EUMax equals CV3EUMin.
CV1LimitsInv BOOL CV1LLimit < 0, CV1HLimit > 100, or
CV1HLimit <= CV1LLimit. If
CV1HLimit <= CV1LLimit, limit CV1
by using CV1LLimit.
CV2LimitsInv BOOL CV2LLimit < 0, CV2HLimit > 100, or
CV2HLimit <= CV2LLimit. If
CV2HLimit <= CV2LLimit, limit CV2
by using CV2LLimit.
CV3LimitsInv BOOL CV3LLimit < 0, CV3HLimit > 100, or
CV3HLimit <= CV3LLimit. If
CV3HLimit <= CV3LLimit, limit CV3
by using CV3LLimit.
CV1ROCLimitInv BOOL CV1ROCLimit < 0, disables CV1 ROC
limiting.
