Allen-Bradley LOGIX 5000

Common Attributes for Advanced Process Control and Drives Instructions
Chapter 11
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 553
• Process Analog Input (PAI)
• Process Analog Output (PAO)
• Alarm (ALM)
• Enhanced Select (ESEL)
• Totalizer (TOT)
• Ramp/Soak (RMPS)
• Discrete 2-State Device (D2SD)
• Discrete 3-State Device (D3SD)
• Enhanced PID (PIDE)
Configure the faceplates through property pages that open through container
applications.
All faceplates have these property pages in common:
• General
• Display
• Font
• Locale
See also
Faceplate Control Properties Dialog - General Tab on page 553
Faceplate Control Properties Dialog - Display Tab on page 554
Faceplate Control Properties Dialog - Font Tab on page 555
Faceplate Control Properties Dialog - LocaleTab on page 556
Use this tab to define/modify how the control operates.
Parameters
Communication
Select RSLinx Classic OPC Server or FactoryTalk Linx. If you select RSLinx
Classic OPC Server, you must also specify:
Faceplate Control
Properties Dialog - General
Tab
