Common Attributes for Advanced Process Control and Drives Instructions
554 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
• whether to launch remotely
• the access path to the remote machine
If you select FactoryTalk Linx FactoryTalk, you must also specify the FactoryTalk
Area
Tag
Enter the name of a specific function block instruction to connect with this
control.
Update Rate
Enter the Update Rate of the control in seconds. You can click the arrows to
increment this value in 0.25 second increments. The default value is 1.00 second.
See also
Faceplate Control Properties Dialog - Display Tab on page 554
Faceplate Control Properties Dialog - Font Tab on page 555
Faceplate Control Properties Dialog - LocaleTab on page 556
Use this tab to define how the faceplate control will appear on your screen.
Parameters
Background Color
This button indicates the color of the faceplate’s background. Click the button to
change this color. The default color is light gray.
Show Frame
Check or uncheck this box, depending on whether or not you wish to display a 3-
dimensional frame around this control. Using this option allows you to separate
the control from other items that may appear on your display. This option is
checked, by default.
OK
Click this button to accept your edits and close the Faceplate Control Properties
dialog.
Properties Dialog - Display
Tab
