Common Attributes for Advanced Process Control and Drives Instructions
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 555
Cancel
Click this button to cancel your edits and close the Faceplate Control Properties
dialog.
Apply
Click this button to apply your edits and continue editing in the Faceplate
Control Properties dialog.
See also
Faceplate Control Properties Dialog - General Tab on page 553
Faceplate Control Properties Dialog - Font Tab on page 555
Faceplate Control Properties Dialog - LocaleTab on page 556
Use this tab to define the fonts that appear on the faceplates. From here, you can
configure a ControlFont to be used in the main part of the faceplate, and a
MinorFont to be used in scales and other minor portions of the faceplate.
Parameters
Property Name
Choose the font you want to configure from the pull-down menu. Choose from
ControlFont or MinorFont; the default is ControlFont.
Font
Choose the font you wish to use for the control from the list of available fonts.
The default font is Arial.
Style
Choose the style you wish to use for the control from the pull-down menu. The
default style is Regular.
Size
Enter the point size you wish to use for this font. The default size of the
ControlFont is 10.5 points; the default size of the MinorFont is 8.25 points.
Strikeout
Check this box if you want to use the strikeout effect, which draws a line through
the font. This option is unchecked, by default.
Properties Dialog - Font Tab
