Input Parameters Data
Type
Description Values
CV2HandFBFault BOOL CV2HandFB value bad health indicator. If the
CV2HandFB value is read from an analog input,
then CV2HandFBFault will normally be controlled
by the status of the analog input channel.
If CV2HandFBFault is TRUE, it indicates an error on
the input module, set bit in Status.
FALSE = Good Health
Default = FALSE
CV3HANDFBFault BOOL CV3HandFB value bad health indicator. If the
CV3HandFB value is read from an analog input,
then CV3HandFBFault will normally be controlled
by the status of the analog input channel.
If CV3HandFBFault is TRUE, it indicates an error on
the input module, set bit in Status.
FALSE = Good Health
Default = FALSE
CV1Target REAL Target value for control variable output 1. Valid = 0.0 through 100.0
Default = 0.0
CV2Target REAL Target value for control variable output 2. Valid = 0.0 through 100.0
Default = 0.0
CV3Target REAL Target value for control variable output 3. Valid = 0.0 through 100.0
Default = 0.0
CV1WindupHIn BOOL CV1Windup high request. When TRUE, CV1 will
not be allowed to increase in value. This signal
will typically be the CV1WindupHOut output from
a secondary loop.
Default = FALSE
CV2WindupHIn BOOL CV2Windup high request. When TRUE, CV2 will
not be allowed to increase in value. This signal
will typically be the CV2WindupHOut output from
a secondary loop.
Default = FALSE
CV3WindupHIn BOOL CV3Windup high request. When TRUE, CV3 will
not be allowed to increase in value. This signal
will typically be the CV3WindupHOut output from
a secondary loop.
Default = FALSE
CV1WindupLIn BOOL CV1 Windup low request. When TRUE, CV1 will
not be allowed to decrease in value. This signal
will typically be the CV1WindupLOut output from
a secondary loop.
Default = FALSE
CV2WindupLIn BOOL CV2 Windup low request. When TRUE, CV2 will
not be allowed to decrease in value. This signal
will typically be the CV2WindupLOut output from
a secondary loop.
Default = FALSE
CV3WindupLIn BOOL CV3 Windup low request. When TRUE, CV3 will
not be allowed to decrease in value. This signal
will typically be the CV3WindupLOut output from
a secondary loop.
Default = FALSE
GainEUSpan BOOL ModelGain units in EU or as % of span. Default = FALSE
FALSE = Gain in % of span
