Input Parameters Data
Type
Description Values
CV3PV1ModelGain REAL The internal model gain parameter for CV3 - PV1.
Enter a positive or negative gain depending on
process direction.
If CV3PV1ModelGain = INF or NAN, set bit in
Status.
Valid = maximum negative
float −> maximum positive
float
Default = 0.0
CV1PV2ModelGain REAL The internal model gain parameter for CV1 - PV2.
Enter a positive or negative gain depending on
process direction.
If CV1PV2ModelGain = INF or NAN, set bit in
Status.
Valid = maximum negative
float −> maximum positive
float
Default = 0.0
CV2PV2ModelGain REAL The internal model gain parameter for CV2 - PV2.
Enter a positive or negative gain depending on
process direction.
If CV2PV2ModelGain = INF or NAN, set bit in
Status.
Valid = maximum negative
float −> maximum positive
float
Default = 0.0
CV3PV2ModelGain REAL The internal model gain parameter for CV3 - PV2.
Enter a positive or negative gain depending on
process direction.
If CV3PV2ModelGain = INF or NAN, set bit in
Status.
Valid = maximum negative
float −> maximum positive
float
Default = 0.0
CV1PV1ModelTC REAL The internal model time constant for CV1 - PV1 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV2PV1ModelTC REAL The internal model time constant for CV2 - PV1 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV3PV1ModelTC REAL The internal model time constant for CV3 - PV1 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV1PV2ModelTC REAL The internal model time constant for CV1 - PV2 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV2PV2ModelTC REAL The internal model time constant for CV2 - PV2 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV3PV2ModelTC REAL The internal model time constant for CV3 - PV2 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV1PV1ModelDT REAL The internal model deadtime for CV1 - PV1 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV2PV1ModelDT REAL The internal model deadtime for CV2 - PV1 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
CV3PV1ModelDT REAL The internal model deadtime for CV3 - PV1 in
seconds.
Valid = 0.0 to maximum
positive float
Default = 0.0
