Process Control Instructions
230 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
Output
Parameters
Data
Type
Description Values
AtuneCV2PV1Abor
ted
BOOL Set True when auto tuning for CV2 - PV1 has been
aborted by user or due to errors that occurred
during the auto tuning operation.
AtuneCV3PV1Abor
ted
BOOL Set True when auto tuning for CV3 PV1 has been
aborted by user or due to errors that occurred
during the auto tuning operation.
AtuneCV1PV2On BOOL Set True with auto tuning for CV1 - PV2 has be
initiated.
AtuneCV2PV2On BOOL Set True with auto tuning for CV2 - PV2 has be
initiated.
AtuneCV3PV2On BOOL Set True with auto tuning for CV3 - PV2 has be
initiated.
AtuneCV1PV2Don
e
BOOL Set True when auto tuning for CV1 - PV2 has
completed successfully.
AtuneCV2PV2Don
e
BOOL Set True when auto tuning for CV2 - PV2 has
completed successfully.
AtuneCV3PV2Don
e
BOOL Set True when auto tuning for CV3 - PV2 has
completed successfully.
ATuneCV1PV2Abor
ted
BOOL Set True when auto tuning for CV1-PV2 has been
aborted by user or due to errors that occurred
during the auto tuning operation.
ATuneCV2PV2Abor
ted
BOOL Set True when auto tuning for CV2-PV2 has been
aborted by user or due to errors that occurred
during the auto tuning operation.
ATuneCV3PV2Abor
ted
BOOL Set True when auto tuning for CV3-PV2 has been
aborted by user or due to errors that occurred
during the auto tuning operation.
AtuneCV1PV1Stat
us
DINT Bit mapped status for CV1 - PV1. A value of 0
indicates that no faults have occurred.
AtuneCV2PV1Stat
us
DINT Bit mapped status for CV2 - PV1. A value of 0
indicates that no faults have occurred.
AtuneCV3PV1Stat
us
DINT Bit mapped status for CV3 - PV1.
A value of 0 indicates that no faults have occurred.
AtuneCV1PV2Stat
us
DINT Bit mapped status for CV1 - PV2. A value of 0
indicates that no faults have occurred.
AtuneCV2PV2Stat
us
DINT Bit mapped status for CV2 - PV2. A value of 0
indicates that no faults have occurred.
AtuneCV3PV2Stat
us
DINT Bit mapped status for CV3 - PV2. A value of 0
indicates that no faults have occurred.
AtuneCV1PV1Fault BOOL CV1 - PV1 Autotune has generated any of the
following faults.
Bit 0 of AtuneCV1PV1Status
AtuneCV2PV1Fault BOOL CV2 - PV1 Autotune has generated any of the
following faults.
Bit 0 of AtuneCV2PV1Status
AtuneCV3PV1Fault BOOL CV3 - PV1 Autotune has generated any of the
following faults.
Bit 0 of AtuneCV3PV1Status
