108 Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017
Chapter 4 Windows CE Operating System
Web Server Configuration
The Web Server tab in the Network Server Configuration dialog box configures
settings that are used for HTTP web activities. These are standard Microsoft
Windows CE parameters.
Always click OK to apply new settings. You are asked if you want to restart the
service immediately.
Table 54 - Web Server Parameters
Parameter Description Default
Admin Users Specifies a list of users allowed to administer web
activities.
When selected, you can enter a list of user names,
separated by semicolons, in the field that opens at the
bottom of the dialog box.
ADMIN
Basic Authentication Check this option to require a user name and password to
access the web server.
Disabled (unchecked)
Default Web Page Specifies default web pages users can access. default.htm;index.htm
Allow Directory Browsing Check this option to let users browse directories on a web
server.
Disabled (unchecked)
Max Connections Specifies the maximum number of incoming web
connections.
256
Log File Directory Specifies the path where the log file is stored. This file logs
web activity.
\windows\www
Max Log Size Specifies the maximum size of the log file stored in the log
file directory.
A new log file is created, when the current log file reaches
the maximum size.
32768 bytes
NTLM Authentication Check this option to require a valid user name and
password to access the web server.
If NTLM Authentication is enabled, you must enter a valid
user name in the Admin Users field.
NTLM user accounts are defined in the User Account
Manager of the control panel.
Enabled (checked)
