140 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019
Chapter 6 Configure Integrated Motion Using a PowerFlex 527 Drive
The New Tag dialog box appears.
2. Type the new motion group name.
3. Click Create.
Your new motion group appears in the Controller Organizer under the
Motion Groups folder.
4. Right-click the new motion group and choose Properties.
The Motion Group Properties dialog box appears.
5. Click the Axis Assignment tab and move your axes (created earlier) from
Unassigned to Assigned.
6. Click the Attributes tab and edit the default values as appropriate for
your application.
7. Click OK.
To get the minimum motion group base-update rate, see Motion Group
Base Update Rate on page 342.
Configure the Axis Properties
After you add the drive to your project and create the axes, use the Axis
Properties dialog boxes to configure the drive. Notice that the dialog boxes
