Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019 21
Chapter 2
Create a Project for Integrated Motion on the
EtherNet/IP Network
This chapter describes how to configure an integrated motion project in the
Logix Designer application.
Create a Controller Project
Follow these instructions to create a project.
1. On the Studio 5000® dialog box, choose Create New Project.
Topic Page
Create a Controller Project 21
Set Time Synchronization 24
Add an Ethernet Communication Module 26
IMPORTANT For Motion and Safety applications, you must use a GuardLogix® or Compact
GuardLogix controller.
To Next Page
