Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019 333

Out of Box Configuration for PowerFlex Drives Appendix B

Settings in Studio 5000

Logix Designer Application

Example Recommended Configuration

PowerFlex 527 PowerFlex 755

Torque Limits 200% of Motor Rated Torque

Velocity Error Tolerance Change action to alarm
