Specifications T30 Series T45 Series
Door Hinge Side Right Right
Door Maximum Open Angle: Degrees 180 180
Gas Models
Gas Connection 1/2 NPT 1/2 NPT
Gas Burner Rating (per pocket):
BTU/hr. [kW, Mj/hr.]
Standard Line
73,000 [21.4, 77.0]
Eco Line
55,000 [16.1, 58.0]
Standard Line
95,000 [27.8, 100.2]
Eco Line
80,000 [23.4, 84.4]
Gas Burner Rating (total machine):
BTU/hr. [kW, Mj/hr.]
Standard Line
146,000 [42.8, 154]
Eco Line
110,000 [32.2, 116]
Standard Line
190,000 [55.6, 200.4]
Eco Line
160,000 [46.8, 169]
Electric Models
Heating Element Rating (per pocket):
Kilowatts
Standard Line - 21
Eco Line - 12
Not Applicable
Table 2
NOTE: "A" market gas machines are shipped with a
BSPT tee fitting mounted on machine. All other IEC ma-
chines are shipped with an adapter to convert the gas
connection threads to BSPT (from NPT).
Specifications and Dimensions
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
21 Part No. 70686701ENR4
