Exhaust Outlet Locations – T30 and T45 Series
Models
Rear Exhaust Dimensions, in. [mm]
Diameter A B C
T30 Series Standard Line
Elliptical Fits 8.0
[200]
Eco Line
Round Fits 6.0
[150]
36.5 [930] 4.3 [110] 62.4 [1,585]
T45 Series Standard Line
Elliptical Fits 10.0
[250]
Eco Line
Elliptical Fits 10.0
[250]
40.9 [1,040] 4.8 [120] 66.0 [1,675]
Table 6
Specifications and Dimensions
©
