Gas Connection Locations – T30 and T45 Series
NOTE: Markets H, J, K, L, R and U have an NPT to BSPT adapter included with machine.
1. A Market 1/2 BSPT; All Other Markets 1/2 NPT
Models
Gas Connection, in. [mm]
A B C
T30 Series 75.5 [1,920] 2.1 [55] 36.4 [925]
T45 Series 79.0 [2,005] 4.5 [115] 42.4 [1,075]
Table 8
Specifications and Dimensions
©
