Installing CE Gas Tumble Dryer
This information is to be used when installing gas tumble dryers
in countries and/or on gases different than the machine’s factory
configuration. Tumble Dryers are supplied from the factory for
operation with natural gas categories 2H, 2E, 2L, 2E(LL), 2E(r),
2E(R) or unregulated L.P.G. categories 3 B/P, 3+. To install tum-
ble dryers for regulated LPG category 3B/P requires a conversion
kit.
Tumble dryers are built in two different configurations:
• Natural Gas – regulated/governor
• Liquefied Petroleum Gas (L.P.G.) – not regulated/no governor
For converting models from Natural Gas to L.P.G., order the ap-
propriate kit listed in Gas Requirements section.
Serial plates supplied from the factory are configured for:
• Natural Gas, standard rate
• AT/BG/CH/CY/CZ/DK/EE/FI/HR/LT/NO/SE/SI/SK:
II
2H3B/P
• CH/ES/GB/GR/IE/IT/TR: II
2H3+
• DE/LU/PL: II
2E3B/P
• Natural Gas, Eco rate
• AT/BG/CH/CY/CZ/DK/EE/ES/FI/GB/GR/HR/IE/IT/LT/N
O/SE/SI/SK/TR: I
2H
• DE/LU/PL: I
2E
• L.P.G.
• BE/CH/ES/FR/GB/GR/IE/IT/TR: I
3+
These instructions pertain to the situations when the country of
use or gas supply is different than that on the serial plate. When
installing in a different country, peel off the appropriate country
sticker (included in literature packet with tumble dryer) and apply
it to the serial plate over the existing country information. Adjust
manifold pressure as applicable, per Table 1.
Units installed in France (FR) require a gas connection adapter
having ISO228 (BSPP, G) parallel threads and a sealing washer.
The adapter must have a sufficient flat area to seat the sealing
washer.
Adjusting Manifold Pressure for
Natural Gas G20 or G25
1. If country/gas category designation required is not listed on
the serial plate, affix the appropriate country/gas category la-
bel supplied over the main serial plate designations.
2. Verify gas supply pressure and adjust as necessary. Refer to
Figure 1.
3. Verify manifold pressure. Refer to How to Adjust Gas Valve
Governor/Regulator and adjust as necessary.
Adjusting Supply Pressure for L.P.G.
G30 or G31
1. If country/gas category designation required is not listed on
the serial plate, affix the appropriate country/gas category la-
bel over the main serial plate designations.
2. Verify gas supply pressure and adjust as necessary. Refer to
Figure 1.
Converting From Natural Gas to L.P.G.
or From Unregulated L.P.G. to
Regulated L.P.G.
1. Refer to table below to determine conversion kit part number
required.
2. Follow instructions supplied in conversion kit.
North
America
Models
Australia
Models
CE Mod-
els
030 Series 70550202 70550214 70551902
T30 Series 70550205 70550211 70551905
035 Series 70550203 70550215 70551903
T45 Series 70550206 70550207 70551906
055 Series 70550204 70550213 70551904
CE GASES refer to Installing CE Gas Tumble Dryer section.
Start-Up Procedure
Turn on gas and check all pipe connections (internal and external)
for gas leaks with a non-corrosive leak detection fluid. Purge air
in gas service line by operating the tumble dryers in the drying
mode. If burner does not light and unit goes into lockout, press
start key on the control while the access panel is open. The con-
trol will then prompt for the start key to be pressed again to re-
start the cycle. Repeat these steps until burner ignites. Use pipe
compound, resistant to actions of L.P. gas, on all pipe threads.
WARNING
Check all pipe connections, internal and external, for
gas leaks using a non-corrosive leak detection fluid.
To reduce the risk of explosion or fire, DO NOT USE
AN OPEN FLAME TO CHECK FOR GAS LEAKS! Gas
connections should be checked daily for leakage.
W924
Gas Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
52 Part No. 70686701ENR4
