Models
Prepurge Time
(seconds)
Interpurge Time
(seconds)
Trial for Ignition
(seconds)
Reset Lockout
Condition By:
North America 1 23 10
(attempts to ignite 3
times)
Automatically resets.
Australia and IEC 23 23 10 Press start key with ac-
cess panel open.
If the tumble dryer does not meet ANY of the listed requirements, remove tumble dryer from use. Refer to Removing Tumble Dryer
from Service section.
Required for IEC Models Only
Once machine is installed, please be sure to complete the follow-
ing items:
• Review and verify machine operation with customer.
• Leave all literature and a signed Declaration of Conformity
with customer.
• Review machine warranty information with customer.
• Apply cautionary stickers in language appropriate to country
of sale. Market language label kits have been provided in the
literature packet located in the cylinder. Position appropriate
market language labels on the machine in the following re-
gions prior to placing machine into service, if applicable:
• On front panel at the periphery of cylinder access opening
• On electrical box cover(s) (electric heat models and stack
tumble dryers have two electrical box covers)
• On rear panel (single dryers) or exhaust duct (stack dry-
ers)
• On front panel near emergency stop button (fire suppres-
sion system equipped models only)
• On fire suppression control box (fire suppression system
equipped models only)
Installation
©
