Gas Connection Locations – 030, 035 and 055 Series
1. T and G Markets 1/2 NPT; All Other Markets 1/2 BSPT
Models
Gas Connection, in. [mm]
A B
030 Series 54.2 [1,375] 1.5 [40]
035 Series 54.2 [1,375] 2.6 [65]
055 Series 55.2 [1,400] 2.5 [65]
Table 7
Specifications and Dimensions
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
26 Part No. 70686701ENR4
