Electrical Connection Locations – 030, 035 and 055 Series
1. Gas and Steam Models: Electrical Connection 1.375 in. [22 mm] Diameter; Electric Models: Electrical Connection Diameter
Models
Electrical Service Dimensions, in. [mm]
A B
030 Series 33.2 [845] 18.5 [470]
035 Series 33.2 [845] 19.6 [500]
055 Series 34.2 [870] 22.3 [565]
Table 9
Specifications and Dimensions
©
