Installation
Pre-Installation Inspection
Upon delivery, visually inspect the crate, carton and parts for any
visible shipping damage. If the crate, carton, or cover is damaged
or signs of possible damage are evident, have the carrier note the
condition on the shipping papers before the shipping receipt is
signed, or advise the carrier of the condition as soon as it is dis-
covered.
Remove the crate and protective cover as soon as possible and
check the items listed on the packing list. Advise the carrier of
any damaged or missing articles as soon as possible. A written
claim should be filed with the carrier immediately if articles are
damaged or missing.
IMPORTANT: Remove the yellow shipping wire tie se-
curing the airflow switch.
IMPORTANT: Warranty is void unless tumble dryer is
installed according to instructions in this manual. In-
stallation should comply with minimum specifications
and requirements detailed in this manual and applica-
ble local gas fitting regulations, municipal building co-
des, water supply regulations, electrical wiring regula-
tions, and any other relevant statutory regulations. Due
to varied requirements, applicable local codes should
be thoroughly understood and all pre-installation work
arranged for accordingly.
Materials Required (Obtain Locally)
All Models Fused disconnect switch or circuit breaker
on 1 Phase models.
Circuit breaker on 3 Phase models.
Gas Models One gas shut-off valve for gas service line
to each tumble dryer.
Table continues...
Materials Required (Obtain Locally)
Steam Models One steam shut-off valve for steam service
line to be connected upstream of solenoid
steam valve.
Two steam shut-off valves for each conden-
sate return line.
Flexible steam hoses with a 125 psig
[pounds per square inch gauge] [862 kPa]
working pressure for connecting steam
coils. Refer to Figure 1 for sizing and con-
nection configurations.
Two steam traps for steam coil outlets to
condensate return line.
Optional – Two vacuum breakers for con-
densate return lines.
IMPORTANT: 3 Phase Only – Each tumble dryer must
be connected to its own individual branch circuit
breaker, not fuses, to avoid the possibility of “single
phasing” and causing premature failure of the mo-
tor(s).
Location Requirements
The machine must be installed on a level floor. Floor covering
materials such as carpeting or tile should be removed.
To assure compliance, consult local building code requirements.
The machine must not be installed or stored in area where it will
be exposed to water and/or weather.
IMPORTANT: DO NOT block the airflow at the rear of
the machine with laundry or other articles. Doing so
would prevent adequate air supply to the combustion
chamber of the machine.
A typical machine enclosure is shown in Figure 2 .
IMPORTANT: Install machines with sufficient clearance
for servicing and operation, refer to Figure 2 .
IMPORTANT: The machine must not be installed be-
hind a lockable door, a sliding door or a door with a
hinge on the opposite side to that of the machine, in
such a way that a full opening of the machine door is
restricted.
Installation
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
31 Part No. 70686701ENR4
