Allweiler NIT Series - Appendix; Sectional Drawings

Appendix
9 Appendix
9.1 Sectional drawings
9.1.1 Auxiliary connections
Abbreviation
Connection
A5, A6 Filling
E6 Vent
FD, FD1 Emptying
LO
Leakage
QF2 Quenching filling
QO2 Quenching egress
Tab. 14 Abbreviations of the connection designations
9.1.2 Part numbers and designations
Part no. Designation
102.06 Volute casing
108.01 Stage casing
118.01 Fan casing
161.10 Housing cover
161.03 Housing cover
161.18 Housing cover
171.01 Diffuser
220.02 Stub shaft
230.05 Impeller
230.02 Impeller, first stage
230.03 Impeller, second stage
321.03 Groove ball bearing
341.01 Motor bell housing
346.01 Pump bracket
363.01 Bearing housing cover
400.01 Gasket
400.02 Gasket
400.03 Gasket
400.13 Gasket
411.01 Seal ring
411.02 Seal ring
411.03 Seal ring
411.14 Seal ring
411.15 Seal ring
411.16 Seal ring
Part no. Designation
411.17 Seal ring
420.01 Shaft seal ring
433.02 Mechanical se al
461.02 Gland packing
509.01 Intermediate ring
514.01 Threaded ring
517.02 Tolerance ring
551.04 Spacer disk
551.06 Spacer disk
558.01 Spacer disk
565.02 Rivet
567.01 Slotted pins
591.01 Container
642.01 Sight glass
672.01 Plug
685.01 Guard sheet
710.01 Pipe
731.01 Pipe fitting
732.01 Holding
736.04 Pipe
738.01 Pipe fitting
801.01 Flanged motor
831.01 Fan
901.01 Hexagon head bolt
901.02 Hexagon head bolt
902.08 Stud bolt
903.01 Screw plug
903.02
Screw p
lug
903.11 Screw plug
903.10 Screw plug
903.12 Screw plug
904.05 Grub screw
914.01 Cheese head screw
914.03 Socket head cap screw
914.04 Socket head cap screw
914.05 Socket head cap screw
914.14 Socket head cap screw
