Following is more detailed information about the blocks in Figure 2-3:
F
F
P
P
G
G
A
A
d
d
e
e
v
v
i
i
c
c
e
e
Cyclone IV EP4CE115F29 device
114,480 LEs
432 M9K memory blocks
3,888 Kbits embedded memory
4 PLLs
F
F
P
P
G
G
A
A
c
c
o
o
n
n
f
f
i
i
g
g
u
u
r
r
a
a
t
t
i
i
o
o
n
n
JTAG and AS mode configuration
EPCS64 serial configuration device
On-board USB Blaster circuitry
M
M
e
e
m
m
o
o
r
r
y
y
d
d
e
e
v
v
i
i
c
c
e
e
s
s
128MB (32Mx32bit) SDRAM
2MB (1Mx16) SRAM
8MB (4Mx16) Flash with 8-bit mode
32Kb EEPROM
S
S
D
D
C
C
a
a
r
r
d
d
s
s
o
o
c
c
k
k
e
e
t
t
Provides SPI and 4-bit SD mode for SD Card access
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
Two Ethernet 10/100/1000 Mbps ports
High Speed Mezzanine Card (HSMC)
Configurable I/O standards (voltage levels:3.3/2.5/1.8/1.5V)
USB type A and B
o Provide host and device controllers compliant with USB 2.0
o Support data transfer at full-speed and low-speed
o PC driver available
