Chapter 5
DE2-115 System Builder
This chapter describes how users can create a custom design project on the DE2-115 board by using
DE2-115 Software Tool – DE2-115 System Builder.
5
5
.
.
1
1
I
I
n
n
t
t
r
r
o
o
d
d
u
u
c
c
t
t
i
i
o
o
n
n
The DE2-115 System Builder is a Windows based software utility, designed to assist users to create
a Quartus II project for the DE2-115 board within minutes. The generated Quartus II project files
include:
 Quartus II Project File (.qpf)
 Quartus II Setting File (.qsf)
 Top-Level Design File (.v)
 Synopsis Design Constraints file (.sdc)
 Pin Assignment Document (.htm)
By providing the above files, DE2-115 System Builder prevents occurrence of situations that are
prone to errors when users manually edit the top-level design file or place pin assignments. The
common mistakes that users encounter are the following:
1. Board damaged for wrong pin/bank voltage assignments.
2. Board malfunction caused by wrong device connections or missing pin counts for connected
ends.
3. Performance degeneration because of improper pin assignments.
5
5
.
.
2
2
G
G
e
e
n
n
e
e
r
r
a
a
l
l
D
D
e
e
s
s
i
i
g
g
n
n
F
F
l
l
o
o
w
w
This section will introduce the general design flow to build a project for the DE2-115 board via the
DE2-115 System Builder. The general design flow is illustrated in Figure 5-1.
Users should launch DE2-115 System Builder and create a new project according to their design
requirements. When users complete the settings, the DE2-115 System Builder will generate two
major files which include top-level design file (.v) and Quartus II setting file (.qsf).
