The DE2-115 development board contains a HSMC interface to provide a mechanism for extending
the peripheral-set of a FPGA host board by means of add-on cards. This can address today‟s high
speed signaling requirement as well as low-speed device interface support. The HSMC interface
support JTAG, clock outputs and inputs, high speed LVDS and single-ended signaling. The HSMC
connector connects directly to the Cyclone IV E FPGA with 82 pins. Signals HSMC_SDA and
HSMC_SCLK share the same bus with the respected signals I2C_SDA and I2C_SCL of the
WM8731 audio ship and ADV7180 TV decoder chip. Table 4-7 shows the maximum power
consumption of the daughter card that connects to HSMC port.
Table 4-7 Power Supply of the HSMC
(1).Note the current levels indicated in Table 4-7 are based on 50% resource consumption.
If the HSMC interface is utilized with design resources exceeding 50%, please notify our support
(support@terasic.com).
(2).If the HSMC loopback adapter is mounted, the I2C_SCL will be directly routed back to
I2C_SDA. Because audio chip, TV decoder chip and HSMC share one I2C bus, therefore audio
and video chip won’t function correctly.
The voltage level of the I/O pins on the HSMC connector can be adjusted to 3.3V, 2.5V, 1.8V, or
1.5V using JP7 (The default setting is 2.5V, see Figure 4-13). Because the HSMC I/Os are
connected to Bank 5 & 6 of the FPGA and the VCCIO voltage (VCCIO5 & VCCIO6) of these
banks are controlled by the header JP7, users can use a jumper to select the input voltage of
VCCIO5 & VCCIO6 to 3.3V, 2.5V, 1.8V, and 1.5V to control the voltage level of the I/O pins.
Table 4-8 lists the jumper settings of the JP7.
