Altera DE2-115 - Page 36

35
Table 4-1 Pin Assignments for Slide Switches
Signal Name
FPGA Pin No.
Description
I/O Standard
SW[0]
PIN_AB28
Slide Switch[0]
Depending on JP7
SW[1]
PIN_AC28
Slide Switch[1]
Depending on JP7
SW[2]
PIN_AC27
Slide Switch[2]
Depending on JP7
SW[3]
PIN_AD27
Slide Switch[3]
Depending on JP7
SW[4]
PIN_AB27
Slide Switch[4]
Depending on JP7
SW[5]
PIN_AC26
Slide Switch[5]
Depending on JP7
SW[6]
PIN_AD26
Slide Switch[6]
Depending on JP7
SW[7]
PIN_AB26
Slide Switch[7]
Depending on JP7
SW[8]
PIN_AC25
Slide Switch[8]
Depending on JP7
SW[9]
PIN_AB25
Slide Switch[9]
Depending on JP7
SW[10]
PIN_AC24
Slide Switch[10]
Depending on JP7
SW[11]
PIN_AB24
Slide Switch[11]
Depending on JP7
SW[12]
PIN_AB23
Slide Switch[12]
Depending on JP7
SW[13]
PIN_AA24
Slide Switch[13]
Depending on JP7
SW[14]
PIN_AA23
Slide Switch[14]
Depending on JP7
SW[15]
PIN_AA22
Slide Switch[15]
Depending on JP7
SW[16]
PIN_Y24
Slide Switch[16]
Depending on JP7
SW[17]
PIN_Y23
Slide Switch[17]
Depending on JP7
Table 4-2 Pin Assignments for Push-buttons
Signal Name
FPGA Pin No.
Description
I/O Standard
KEY[0]
PIN_M23
Push-button[0]
Depending on JP7
KEY[1]
PIN_M21
Push-button[1]
Depending on JP7
KEY[2]
PIN_N21
Push-button[2]
Depending on JP7
KEY[3]
PIN_R24
Push-button[3]
Depending on JP7
Table 4-3 Pin Assignments for LEDs
Signal Name
FPGA Pin No.
Description
I/O Standard
LEDR[0]
PIN_G19
LED Red[0]
2.5V
LEDR[1]
PIN_F19
LED Red[1]
2.5V
LEDR[2]
PIN_E19
LED Red[2]
2.5V
LEDR[3]
PIN_F21
LED Red[3]
2.5V
LEDR[4]
PIN_F18
LED Red[4]
2.5V
LEDR[5]
PIN_E18
LED Red[5]
2.5V
LEDR[6]
PIN_J19
LED Red[6]
2.5V
LEDR[7]
PIN_H19
LED Red[7]
2.5V
LEDR[8]
PIN_J17
LED Red[8]
2.5V
LEDR[9]
PIN_G17
LED Red[9]
2.5V
LEDR[10]
PIN_J15
LED Red[10]
2.5V
LEDR[11]
PIN_H16
LED Red[11]
2.5V
LEDR[12]
PIN_J16
LED Red[12]
2.5V
LEDR[13]
PIN_H17
LED Red[13]
2.5V
LEDR[14]
PIN_F15
LED Red[14]
2.5V
