37
HEX0[5]
PIN_J22
Seven Segment Digit 0[5]
Depending on JP7
HEX0[6]
PIN_H22
Seven Segment Digit 0[6]
Depending on JP7
HEX1[0]
PIN_M24
Seven Segment Digit 1[0]
Depending on JP7
HEX1[1]
PIN_Y22
Seven Segment Digit 1[1]
Depending on JP7
HEX1[2]
PIN_W21
Seven Segment Digit 1[2]
Depending on JP7
HEX1[3]
PIN_W22
Seven Segment Digit 1[3]
Depending on JP7
HEX1[4]
PIN_W25
Seven Segment Digit 1[4]
Depending on JP7
HEX1[5]
PIN_U23
Seven Segment Digit 1[5]
Depending on JP7
HEX1[6]
PIN_U24
Seven Segment Digit 1[6]
Depending on JP7
HEX2[0]
PIN_AA25
Seven Segment Digit 2[0]
Depending on JP7
HEX2[1]
PIN_AA26
Seven Segment Digit 2[1]
Depending on JP7
HEX2[2]
PIN_Y25
Seven Segment Digit 2[2]
Depending on JP7
HEX2[3]
PIN_W26
Seven Segment Digit 2[3]
Depending on JP7
HEX2[4]
PIN_Y26
Seven Segment Digit 2[4]
Depending on JP7
HEX2[5]
PIN_W27
Seven Segment Digit 2[5]
Depending on JP7
HEX2[6]
PIN_W28
Seven Segment Digit 2[6]
Depending on JP7
HEX3[0]
PIN_V21
Seven Segment Digit 3[0]
Depending on JP7
HEX3[1]
PIN_U21
Seven Segment Digit 3[1]
Depending on JP7
HEX3[2]
PIN_AB20
Seven Segment Digit 3[2]
Depending on JP6
HEX3[3]
PIN_AA21
Seven Segment Digit 3[3]
Depending on JP6
HEX3[4]
PIN_AD24
Seven Segment Digit 3[4]
Depending on JP6
HEX3[5]
PIN_AF23
Seven Segment Digit 3[5]
Depending on JP6
HEX3[6]
PIN_Y19
Seven Segment Digit 3[6]
Depending on JP6
HEX4[0]
PIN_AB19
Seven Segment Digit 4[0]
Depending on JP6
HEX4[1]
PIN_AA19
Seven Segment Digit 4[1]
Depending on JP6
HEX4[2]
PIN_AG21
Seven Segment Digit 4[2]
Depending on JP6
HEX4[3]
PIN_AH21
Seven Segment Digit 4[3]
Depending on JP6
HEX4[4]
PIN_AE19
Seven Segment Digit 4[4]
Depending on JP6
HEX4[5]
PIN_AF19
Seven Segment Digit 4[5]
Depending on JP6
HEX4[6]
PIN_AE18
Seven Segment Digit 4[6]
Depending on JP6
HEX5[0]
PIN_AD18
Seven Segment Digit 5[0]
Depending on JP6
HEX5[1]
PIN_AC18
Seven Segment Digit 5[1]
Depending on JP6
HEX5[2]
PIN_AB18
Seven Segment Digit 5[2]
Depending on JP6
HEX5[3]
PIN_AH19
Seven Segment Digit 5[3]
Depending on JP6
HEX5[4]
PIN_AG19
Seven Segment Digit 5[4]
Depending on JP6
HEX5[5]
PIN_AF18
Seven Segment Digit 5[5]
Depending on JP6
HEX5[6]
PIN_AH18
Seven Segment Digit 5[6]
Depending on JP6
HEX6[0]
PIN_AA17
Seven Segment Digit 6[0]
Depending on JP6
HEX6[1]
PIN_AB16
Seven Segment Digit 6[1]
Depending on JP6
HEX6[2]
PIN_AA16
Seven Segment Digit 6[2]
Depending on JP6
HEX6[3]
PIN_AB17
Seven Segment Digit 6[3]
Depending on JP6
HEX6[4]
PIN_AB15
Seven Segment Digit 6[4]
Depending on JP6
HEX6[5]
PIN_AA15
Seven Segment Digit 6[5]
Depending on JP6
HEX6[6]
PIN_AC17
Seven Segment Digit 6[6]
Depending on JP6
HEX7[0]
PIN_AD17
Seven Segment Digit 7[0]
Depending on JP6
HEX7[1]
PIN_AE17
Seven Segment Digit 7[1]
Depending on JP6
