Connect a headset or speaker to the DE2-115 board and you should be able to hear the music
played from the SD Card
Press KEY3 on the DE2-115 board to play the next music file stored in the SD Card.
Press KEY2 and KEY1 to increase and decrease the output music volume respectively.
Users can also use the remote control to play/pause the music, select the last/next music file to
play and control volume. The detailed information about each function of remote controller is
shown in Table 6-1.
Table 6-1 Detailed information of the button on the remote controller
Note:
1. Execute the batch file DE2_115_SD_Card_Audio_Player\demo_batch
\ DE2_115_SD_Card_Audio_Player.bat to download both hardware and software bit stream
2. If the capacity of your SD Memory Card is more than or equal 8GB, please make sure it has
the performance more than or equal to Class 4
3. If the HSMC loopback adapter is mounted, the I2C_SCL will be directly routed back to
I2C_SDA. Because audio chip, TV decoder chip and HSMC share one I2C bus, therefore audio
and video chip won’t function correctly.
Figure 6-15 illustrates the setup for this demonstration.
