Alto-Shaam AR-7T

Installation
MN-39404 • Rev 0 • 05/18 • AR-7T Series Electric Rotisserie Manual 17
Capacity
98 lb (44 kg) maximum
Angled spits (standard):
Up to twenty-one (21) 3-1/2 lb chickens (1,6 kg)
Up to twenty-eight (28) 2-1/2 to 3 lb chickens (1,1 to 1,4 kg)
Piercing spits (optional):
Up to twenty-eight (28) 2-1/2 to 3-1/2 lb chickens (1,1 to 1,6 kg)
Turkey spit (optional): (up to 3 spits can be used)
One (1) Turkey up to 25 lb (11 kg) on each spit
Baskets (optional):
Up to twenty-one (21) 3-1/2 lb chickens (1,6 kg)
Left side 11" (279mm)
Rear 0" (0mm)
Right side 0" (0mm)
Minimum Clearance Requirements
Le 11" (279mm)
Right 0" (0mm)
Rear 0" (0mm)
Top 0" (0mm)
Bottom 0" (0mm)
