21
TO SEE CHANNEL 40 FROM CHANNEL 21
PRESS
→
TENS
PRESS
→
TENS
PRESS
UNITS
↓
TIMERS ACTIVE
STATUS TIMERS ACTIVE
NOT ARMED
CHAN 21
LB MANIFOLD PRESSURE
TO SEE CHANNEL 41 FROM CHANNEL 40
PRESS
↑
UNITS
STATUS RUNNING
ARMED
CHAN 40 83 PSIG
COMP OIL PRESSURE
RUNNING
TO EXIT VIEW CHANNELS MODE
PRESS
ESC
STATUS RUNNING
ARMED
CHAN 41 10.5 PSIA
SUCTION PRESSURE
RUNNING
12.0 SHUTDOWN OR FAULT STATUS SCREENS
12.1 With the engine running and the controller system monitoring points, if a fault
occurs, the display will show the first fault detected. The phrase 1ST FAULT and
AL12 will be displayed; AL1 is for the first output, AL12 is for outputs one and
two. The output or outputs configured for that channel will trip. The first fault
will stay displayed on the screen until it is acknowledged by one of the keypad
keys RESET or ESC. Use VIEW CHAN key to view the status of all channels.
After all of the current faulted channels are displayed, the display will revert to
the first fault. If no class A sensors are faulted, pressing the RESET key will clear
all displayed faults and return the display to the timers active home screen. All
class B and C input timers and the output timers will be reset. Pressing the ESC
key when the fault screen is displayed will return the display to the fault home
screen. To again view the first fault from the fault home screen, press the VIEW
CHAN key.
STATUS TIMERS ACTIVE
NOT ARMED
CHAN 21
LB MANIFOLD PRESSURE
STATUS RUNNING
ARMED
CHAN 40 83 PSIG
COMP OIL PRESSURE
STATUS RUNNING
ARMED
CHAN 41 10.5 PSIA
SUCTION PRESSURE
