CONFIGURE: Allows system configuration in one of three ways:
•
create a new application from a default file
•
upload an existing program from another DE device of the
same part no.
•
load a previously saved disk file
The user can then edit any parameter.
DOWNLOAD: A previously saved disk file can be downloaded directly to the
DE device.
PRINT: The user can print out the data from a saved disk file.
MONITOR: The user can remotely monitor a DE system.
HOST MODE: PC modem monitors for an incoming call from the DE system.
EXIT: Terminates the DE terminal program.
30.4 Configure DE-3000 Device
A. Create New - loads the DEFAULT.PGx file into the program.
B. Retrieve from DE-3x00 - uploads the data from another DE-3x00 and
loads it into the program.
C. Retrieve from File - loads the user selected file into the program. A
file selection box will appear. Double click on the file you want to use.
Version 2.X provides file-conversion support for .PG6 files. If there
exists a saved .PG6 configuration file (with the corresponding .T1tr6
and .T2tr6 files where applicable), the terminal program will convert
the 1.X configuration into an equivalent 2.X one. Once it has been
converted, it is possible to utilize any new features included only in
the 2.X version and then save the file as a .PG7. THE DE-3000 STILL
CAN ONLY BE PROGRAMMED THROUGH THE 2.X TERMINAL PRO-
GRAM IF ALL TERMINAL AND DISPLAY BOARD FIRMWARE FOR
THE DEVICE IS DATED 2014 OR LATER.
D. Cancel - cancels the operation and returns the user to the main form.
Program Global Variables
A. Annunciator Node Number - used in remote communications.
Valid numbers are 1-99.
B. Timer Intervals - all timers have valid values of 1-999. The class C
timer is in minutes; all other timers are in seconds. Version 2.X allows
channels to be configured for cool-down functionality. The timer for
cool-down channels is set here.
C. Output module selection:
1. NO - normally open
2. NC - normally closed
3. Ign/Fuel Valve Module - special module
D. Assign to Stop Function - this determines if the output will trip when
STOP is selected.
E. Data Logging Selections:
1. Header - this 30 character field will be the heading of the datalog
report. It can consist of alphanumeric ASCII characters along with
# % + - . /
2. Data Logging Interval - time between event logging. Valid values
are 1-999 minutes.
3. Continue Data Logging After a Shutdown - Yes/No selects whether
data logging will continue after a shutdown occurs.
F. OEM Engine Control (Version 2.X) and AutoStart - enable and
configure either the OEM Engine control or Autostart sequences and
the Multi-Start functionality (Version 2.X)
