G. Terminal Board Tab
1. Identification - board type and firmware date
2. Solenoid Pulse Control - enable digital outputs for solenoid pulse
control
a. unload pulse on stop/fault - time (seconds) that solenoid will
unload after a stop or fault
3. Pulses per Revolution - for magnetic pickup on speed input
4. Integrated Timer Output (Version 2.X) - set up digital output to
turn ON at startup and remain ON after a stop/fault for specified
amount of time (minutes)
5. Alarm - enable digital output for alarm when channels use this
digital output for a control assignment
6. Service Meter Expiration - set up this digital output to turn on and
remain on when a service meter expires
7. Fault Condition - set up this digital output to turn on and remain on
when a fault occurs
H. Save Global Data - saves current selections and loads the next form.
I. Cancel - cancels current operation and returns user to the main form.
Program Channels form appears
A. Channel Number - select the channel number from the drop down list
that you would like to program.
B. User Label - this is a 20 character label that defines the channel
operation. It can consist of alphanumeric ASCII characters along with
# % + - . /
C. SAVE Button - saves the current channel label to the default label file,
so it can be selected from the drop down list.
D. Input Type - Channels 1-60 can be a discrete or analog device.
E. Input Class - selects whether input class is type A, B or C.
F. Time in seconds or minutes.
1. Input Class A - no time defined, instant trip. The time box is disabled.
2. Input Class B - time may be defined from 1-999 seconds.
3. Input Class C - global class C time displayed in minutes. Time box
is disabled.
G. Output Assignments - check any or all outputs to trip when a discrete
input switches out of normal state or when an analog input exceeds
the control range.
H. Previous Screen - closes current form and loads Program Global
Variables form.
I. Previous Channel - decrements selected channel.
J. Next Channel - increments selected channel.
K. Save Channel Data - saves current selections and loads the next form.
L. Cancel - cancels current operation, returns user to main form.
M. Differential - two consecutive analog input channels can be set up for
differential measurement when this box is checked. The first chan-
nel selected for differential will still measure that channel’s individual
input and evaluate the safety and control setpoints for that input. The
second channel will measure the difference between the two chan-
nels’ inputs (1st channel minus 2nd channel) and evaluate the safety
and control setpoints based on the differential measurement.
N. Cool-down - input class B or C channels can be set up for the cool-
down function when this box is checked (Version 2.X only)
O. Lube No-Flow - Channels 27 and 28 can be configured for lube
monitoring when an analog input is selected and this box is checked
(Version 2.X). Doing so sets up the sensor type on the screen and al
lows a maximum time between pulses to be entered.
