DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
57
Program Control Values form appears
A. PID - setup control parameters for corresponding analog output number
B. Solenoid Pulse Control - input channel 3 can control digital outputs 1
and 2 to be used for solenoid pulse control
C. Cascade RPM/LOAD Control - configure A02 for Cascade Control
D. Linear/Ramp Control - (Version 2.X only) configure A02 for Linear/
Ramp Control. The DE-3000 will create a linear relationship between
the value of Channel 1 and the output current. It is up to the user to
map an accurate RPM value to the min and max output limit.
Program Home Screen Values form appears
A. Select the corresponding channel numbers to display the serial infor-
mation on the display home screen. Valid values are 160.
B. Previous Screen - closes current form and loads Program Channel
Values form.
C. Save Labels - saves current selections and loads the next form.
D. Cancel - cancels current operation, returns user to main form.
Program View Process Screen form appears
A. Select the corresponding channel numbers to display the serial infor-
mation for the display view process screens. Valid values are 1–60.
B. Previous Screen - closes current form and loads Program Home
Screen Values form.
C. Save Labels - saves current selections, loads the next form.
D. Cancel - cancels current operation, returns user to main form.
Display Configuration form appears
A. Previous Screen - closes current form and loads Program View
Process Screens form.
B. Program DE-3x00 - this takes the current data set and saves it to the
download.PGx file, then programs the DE device and verifies that
programming was completed successfully.
C. Save to File - this creates a PGx file. This file can be used at a later
date to program the unit, or used for reference purposes.
D. Print Data - the user can print out the chart on this form for reference
purposes.
E. Cancel - cancels current operation, returns user to main form.
30.5 DOWNLOAD
This allows the user to select any PGx file that they’d like to use to program
the DE-3x00. The DE-3x00 is then programmed and verified that programming
was completed successfully.
30.6 PRINT
The user can select a PGx file to print out. The data grid will be loaded with the file
data. PRINT will print the data, CANCEL will exit and return the user to the main form.
30.7 MONITOR
In this main screen, the text box will display data communications from the PC
to the DE system via a modem. If the terminal is connected to the device, the
current Home Screen and View Process screen values will be displayed. If no
connection is established, the values in these boxes will be N.C. (no connection)
30.8 MONITOR DE-3x00
A. Connect to DE-3x00 - initiates the call to establish communications
with the DE system.
B. Hangup - terminates a call.
