DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
22
1
ST
FAULT
STATUS FAULT AL12
1st FAULT
CHAN 24
HIGH LIQUID LEVEL 1
OR PRESS
ESC FOR
FAULT HOME
SCREEN
ESC
PRESS
TO RESET
TIMERS AND
OUTPUTS
RESET
TIMERS ACTIVE
STATUS TIMERS ACTIVE
SPEED 330 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
12.2 When a fault occurs on an analog channel, a HIGH or LOW indication will ad-
ditionally be displayed as to whether the point faulted on a high or low setpoint.
PRESS TO
RESET AND
TO CLEAR
FAULT
RESET
1
ST
FAULT
STATUS FAULT AL12
1st FAULT HIGH
CHAN 42 300 °F
HIGH DISCHARGE TEMP
A HIGH
SETPOINT
FAULTED ON
AN ANALOG
INPUT. THE
ANALOG
VALUE AND
“HIGH” ARE
DISPLAYED.
13.0
TEST MODE SCREENS
13.1 The test mode is used for testing sensors without tripping the outputs. The con-
troller system stays in the test mode for a preset timed period. To enter the test
mode, make sure the home screen status line says RUNNING, and press the
TEST key on the keypad. The status line will display TEST xxx SEC; xxx being the
remaining test time. To test an input, momentarily fault a sensor. The display will
show the faulted point, its description and 1st FAULT for the first point tested. To
test another point press the TEST key, this will clear the tested sensor from the
display and will refresh the test timer to its full programmed test time.
PRESS TO
ENTER TEST
MODE
TEST
TEST MODE
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102 PSIA
DISCHARGE 200 PSIG
TEST SCREEN IS SHOWN WITH NO FAULTED POINTS. TEST KEY WAS PRESSED FROM
THE “RUNNING” HOME SCREEN.
STATUS FAULT AL12
1st FAULT
CHAN 24
HIGH LIQUID LEVEL 1
STATUS TIMERS ACTIVE
SPEED 330 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
STATUS FAULT AL12
1st FAULT HIGH
CHAN 42 300 °F
HIGH DISCHARGE TEMP
WARNING: TEST MODE DISARMS ALL
OUTPUTS. ACTUAL FAULTS WILL DIS-
PLAY BUT WILL NOT TRIP THE SYSTEM
ALARM AND SHUTDOWN OUTPUTS.
USE MANUAL STOP FOR EMERGENCY
SHUTDOWN.
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102 PSIA
DISCHARGE 200 PSIG
