15.0
VIEWING/EDITING THE CONFIGURATION USING THE MENU MODE
15.1 The menu screens can be accessed from any home screen (except test) by
pressing the MENU key. The menu screens allow the user to view or edit global
values, and the time and date. The controller must be initially configured using
the terminal program running on a PC connected to the RS-232 or USB port
on the back of the controller. Reference the programming instructions (section
30.0) for instructions on how to configure the controller system for a specific
application. The menu screens are intended to view or edit the already pro-
grammed values in the field. Changes made in the menu are stored in perma-
nent memory and remain fixed until changed again. Listed below are the values
that can be viewed or edited:
VIEW or EDIT THE GLOBAL VALUES:
TEST TIME — from 1 to 999 seconds
NODE NUMBER — from 1 to 99 (default is 1)
CLASS C TIMER — from 1 to 999 minutes
VIEW THE INPUT CLASS:
The input class options are:
— Class A — no time delay on start-up
— Class B — 10 to 999 seconds time delay on start-up before input is active
— Class C — safe-until-first-met with a global time delay
VIEW or EDIT THE OUTPUT CONFIGURATION:
CONFIGURATION
— N/O (Normally-open) open in the normal run state and closes upon a fault
— N/C (Normally-closed) closed in the normal run state and opens upon a
fault or loss of 12-24Vdc input power
— IGN (Ignition Shorting and Fuel Valve Trip Module, Altronic P/N 691124
open in the normal run state and closes upon a fault or loss of 12-24Vdc
ACTIVATION DELAY TIME — from 0 to 99 seconds
VIEW or EDIT THE TIME AND DATE:
TIME or DATE
15.2 To VIEW the controller configuration from the home screen, press the MENU
key. Use the NEXT key to select the group to be viewed and press ENTER. To
EDIT the controller configuration, the controller system requires a password key
sequence. See section 27.0
15.3 The following keys have the same effect in all of the menu screens. If no key is
pressed within one minute, the menu screen will time out and return to the cur-
rent home screen.
NEXT: The NEXT key moves the selection arrow to the next selection or
value with making a change to the previous value.
↑
UNITS: The
↑
UNITS key moves the selection arrow up one selection or in
creases the value by one.
↓
UNITS: The
↓
UNITS key moves the selection arrow down one selection or
decreases the value by one.
→
TENS: The
→
TENS key increases the value by ten.
←
TENS: The
←
TENS key decreases the value by ten.
ENTER: The ENTER key saves the new value and advances the selection
arrow to the next value to be changed.
ESC: The ESC key returns the display back to the previous level of menu
screens and when pressed again back to the current home screen.
