15.4 The menu screens have two levels. The first level lists the headings of the items
to be viewed or edited. Upon selecting one of the headings, the second level is
displayed. Press the MENU key to enter the first level of the menu screens. The
arrow points to the first selection to be viewed or edited. Three keys can be used
to navigate the first level of menu selections, NEXT or
↑
UNITS or
↓
UNITS keys.
The NEXT key will move the arrow down one selection. The
↑
UNITS or
↓
UNITS
keys will move the selector arrow up or down one selection. Once the arrow is
pointing to the selection group to be edited, press the ENTER key. The display
will advance to the second level to view or allow changes to the values.
PRESS
TO ENTER
THE MENU
SCREENS
MENU
RUNNING
~EDIT CONTROL VALUES
EDIT SAFETY SHUTDOWN
HOURMETER FUNCTIONS
VIEW FIRMWARE REV.
Use the following keys to navigate the menu screen.
PRESS
TO SHOW
SELECTION
ARROW
NEXT
PRESS TO
MOVE SELEC-
TION ARROW
DOWN
UNITS
↓
PRESS
TO MOVE
SELECTION
ARROW UP
↑
UNITS
15.5 To edit the setpoint values, point to EDIT CONTROL VALUES and press the ENTER
key. The edit control values menu is shown. The arrow points to EDIT SETPOINTS.
PRESS
TO EDIT
SETPOINTS
ENTER
~EDIT SETPOINTS
EDIT CONTROLS
EDIT PID DEAD BAND
CALIBRATION
RUNNING
CHAN ~01 (CONTROL)
LO SP 20.0 PSIA
HI SP 60.0 PSIA
MANIFOLD PRESSURE
RUNNING
~EDIT CONTROL VALUES
EDIT SAFETY SHUTDOWN
HOURMETER FUNCTIONS
VIEW FIRMWARE REV.
~EDIT SETPOINTS
EDIT PRIM. CONTROLS
EDIT PID DEAD BAND
CALIBRATION
CHAN ~01 (CONTROL)
LO SP 20.0 PSIA
HI SP 60.0 PSIA
MANIFOLD PRESSURE
