15.6 To edit Primary Controls or Linear/Ramp Control, first select EDIT CONTROL
VALUES from main menu and press the ENTER key. The edit control values
menu is shown. The arrow points to EDIT CONTROLS.
EDIT SETPOINTS
~EDIT CONTROLS
EDIT PID DEAD BAND
CALIBRATION
RUNNING
PRESS
TO EDIT
CONTROLS
ENTER
>LINEAR/RAMP CONTROL
EDIT PRIM. CONTROLS
RUNNING
PRESS
TO EDIT
LIN/RAMP
CONTROLS
ENTER
To edit Linear/Ramp Control, in the EDIT CONTROLS screen, select LINEAR/
RAMP CONTROL and press enter.
VAR LOW > 5.0 PSIA
OP LIMIT 6.0 mA
VAR HIGH 20.0 PSIA
OP LIMIT 17.9 mA
RUNNING
Here the low and high setpoints and corresponding currents can be adjusted
using the up/down or left/right arrows. Once a desired value has been pro-
grammed, press ENTER to move to the next parameter. To edit the Solenoid
Pulse Control, in the EDIT CONTROLS screen, select EDIT PRIM. CONTROLS
and press ENTER.
CONTROL ~ 18.0 PSIA
CYCLE TIME 5 s
PROP. BAND 40 %
DEAD BAND 2.2 PSIA
RUNNING
EDIT SETPOINTS
~EDIT PRIM. CONTROLS
EDIT PID DEAD BAND
CALIBRATION
CONTROL ~ 18.0 PSIA
CYCLE TIME 5 s
PROP. BAND 40 %
DEAD BAND 2.2 PSIA
