DE-3000 IOI 7-17

15.7 To edit PID Deadband, select EDIT PID DEADBAND and press ENTER.

EDIT SETPOINTS

EDIT CONTROLS

~EDIT PID DEADBAND

CALIBRATION

RUNNING

PRESS TO

EDIT PID

DEADBAND

ENTER

Use the ENTER key to select which PID DEADBAND to modify. Use the arrow

keys to change the values.

PID #1

DEADBAND~ 0.0 PSIA

PID #2

DEADBAND 2.5 PSIA

RUNNING

15.8 The calibration feature allows the user to make adjustments in order to ‘tweak’

the sensor’s reading to best match known conditions. For each analog input, the

ZERO and SPAN values may be modiﬁed.

EDIT SETPOINTS

EDIT CONTROLS

EDIT PID DEADBAND

~CALIBRATION

RUNNING

CHAN ~01

ZERO CALIBRATION

SPAN CALIBRATION

23.1 PSIA

RUNNING

From this menu, the UP and DOWN arrow keys are used to select the analog

channel which needs to be calibrated. The value on the bottom shows the actual

value of that channel which is being calibrated. Make sure to enter the password

to modify the calibration.

EDIT SETPOINTS

EDIT PRIM. CONTROLS

~EDIT PID DEADBAND

CALIBRATION

PID #1

DEADBAND~ 0.0 PSIA

PID #2

DEADBAND 2.5 PSIA

EDIT SETPOINTS

EDIT PRIM. CONTROLS

EDIT PID DEADBAND

~CALIBRATION

CHAN ~01

ZERO CALIBRATION

SPAN CALIBRATION

23.1 PSIA
