DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
29
CHAN 01
~ZERO CALIBRATION
SPAN CALIBRATION
14.5 PSIA
RUNNING
PRESS TO
SELECT ZERO
CALIBRATION
ENTER
The ZERO CALIBRATION adjustment allows the user to increase or decrease the
zero calibration of an analog channel. Pressing the UP arrow key several times
will increase the displayed value.
CHAN 01
~ZERO CALIBRATION
SPAN CALIBRATION
14.7 PSIA
RUNNING
The previous example could be used to calibrate a pressure sensor to sea level.
Changing the ZERO CALIBRATION will have the same effect to the high end of
the transducer range as the low.
CHAN 01
ZERO CALIBRATION
~SPAN CALIBRATION
145.6 PSIA
RUNNING
PRESS TO
SELECT SPAN
CALIBRATION
ENTER
The SPAN CALIBRATION adjustment allows the user to increase or decrease the
span calibration of an analog channel. Pressing the UP arrow key several times
will increase the displayed value.
Unlike the zero calibration, the span calibration will have a larger change for
higher numbers.
15.9 To view or edit safety shutdown values, choose EDIT SAFETY SHUTDOWN from
the main menu. To edit or view setpoints choose EDIT SETPOINTS.
EDIT CONTROL VALUES
~EDIT SAFETY SHUTDOWN
HOURMETER FUNCTIONS
VIEW FIRMWARE REV.
RUNNING
CHAN 01
~ZERO CALIBRATION
SPAN CALIBRATION
14.5 PSIA
CHAN 01
~ZERO CALIBRATION
SPAN CALIBRATION
14.7 PSIA
CHAN 01
ZERO CALIBRATION
~SPAN CALIBRATION
145.6 PSIA
EDIT CONTROL VALUES
~EDIT SAFETY SHUTDOWN
HOURMETER FUNCTIONS
VIEW FIRMWARE REV.
