DE-3000 IOI 7-17

~EDIT SETPOINTS

EDIT INPUT CLASS

EDIT GLOBAL VALUES

MORE MENUS

RUNNING

CHAN ~01 (SAFETY)

LO SP 20.0 PSIA

HI SP 60.0 PSIA

MANIFOLD PRESSURE

RUNNING

15.10 To view input class, choose EDIT SAFETY SHUTDOWN from main menu. Select

VIEW INPUT CLASS from next menu.

EDIT SETPOINTS

~EDIT INPUT CLASS

EDIT GLOBAL VALUES

MORE MENUS

RUNNING

CHAN ~01

INPUT CLASS ©A B C

300 SECONDS TIME

DELAY ON START-UP

RUNNING

Channel 01’s input class conﬁguration will be displayed. Each input channel

01–60 can be either class A, B, or C. The class for analog input channels is pro-

grammed in the terminal program using the PC, both the high and low setpoints

of these channels are individually selectable. A diamond next to the input class

letter selects that class for the displayed channel.

~EDIT SETPOINTS

EDIT INPUT CLASS

EDIT GLOBAL VALUES

MORE MENUS

CHAN ~01 (SAFETY)

LO SP 20.0 PSIA

HI SP 60.0 PSIA

MANIFOLD PRESSURE

EDIT SETPOINTS

~EDIT INPUT CLASS

EDIT GLOBAL VALUES

MORE MENUS

CHAN ~01

300 SECONDS TIME

DELAY ON START-UP
