SENSOR
POINT 24
IS TESTED
PRESS
TO TEST
ANOTHER
SENSOR
TEST
TEST MODE
STATUS TEST 525 SEC
1st FAULT
CHAN 24
LIQUID LEVEL STAGE 1
13.2 When any of the analog channels are tested, a HIGH or LOW indication will be
displayed indicating whether a high or low setpoint was tested. The display will
show the current analog value for the channel selected.
A HIGH
SETPOINT
FAULTED ON
AN ANALOG
INPUT
TEST MODE
STATUS TEST 530 SEC
1st FAULT
CHAN 33 5 PSIA
HIGH FILTER PRESS
13.3 If no sensors are faulted and the TEST key is pressed, the display will return
to the test home screen. The test timer will be reset and speed, suction and
discharge values will be displayed.
PRESS
TEST
TEST MODE
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
13.4 To exit the test screen, press either the ESC or CANCEL TIMERS key. Pressing the
CANCEL TIMERS key takes the user to the STATUS RUNNING home screen and
does not reset the class B, C and output timers. Pressing the RESET key takes the
user to the STATUS TIMERS ACTIVE home screen with the class B, C and output
timers reset.
PRESS
CANCEL
TIMERS
STATUS RUNNING
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
RUNNING
STATUS TEST 525 SEC
1st FAULT
CHAN 24
LIQUID LEVEL STAGE 1
STATUS TEST 530 SEC
1st FAULT
CHAN 33 5 PSIA
HIGH FILTER PRESS
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
STATUS RUNNING
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
