18.5 The DE-3000 system uses a simple ASCII command to read the data collected.
The ASCII command must be transmitted to the controller by the PC or PLC
before it can respond. The command is shown below. The hexadecimal values
for the characters are shown only for those using low level (assembly language)
decoding and will not appear on the communications terminal screen.
ASCII >(01 DL 001)
HEX 3Eh 28h 30h 32h 20h 44h 4Ch 20h 30h 30h 32h 29h
COMMAND HEADER “>” (3Eh) The command must begin with the command
header.
START OF TEXT “(“ (28h) The start of text character must be next.
NODE NUMBER 01–99 The node number or address of the controller being contact-
ed is next. This number is programmed by the terminal program and can be viewed
or edited in the menu screen. A two digit number from 01 to 99 can be used.
SPACE (20h) Following the node number is an ASCII space character (not print-
able, value 20h) to act as a delimiter between the node number and the two char-
acter command word.
COMMAND WORD “DL” (44h, 4Ch) The command is an upper case DL for data log.
SPACE (20h) A space again is used as a delimiter.
RECORD NUMBER 001–100 The record number is the requested record. This num-
ber can be any number from 001 to 100. Record number 001 always contains the
most recent record, 002 the second most recent and so on. The controller holds a
maximum of 100 records in its memory before overwriting the oldest record.
END OF TEXT “)” (29h) The end of text completes the message.
18.6 One record contains the following information:
COMP. STATION #01 GIRARD, OHIO User entered data log header describing location
001 10333 HRS Record number and running hours
10 -19 -1998 9 :46 AM Date/time the record information was collected
STATUS RUNNING Normal home screen status line
SPEED 925 RPM Normal home screen, line two
SUCTION 102.3 PSIA Normal home screen, line three
DISCHARGE 300 PSIG Normal home screen, line four
PRESS 1 102.3 PSIG * First view process screen, line one
PRESS 2 355 PSIG * First view process screen, line two
PRESS 3 250 PSIG * First view process screen, line three
PRESS 4 275 PSIG * First view process screen, line four
TEMP 1 55 °F * Second view process screen, line one
TEMP 2 170 °F * Second view process screen, line two
TEMP 3 180 °F * Second view process screen, line three
TEMP 4 190 °F * Second view process screen, line four
TEMP 5 220 °F * 11th Analog channel value
PRESS 5 22 PSIA * 12th Analog channel value
USER LABEL * 13th Analog channel value
USER LABEL * 14th Analog channel value
1ST FAULT HIGH ** First fault indication when fault occurs
CHAN A3 500 PSI ** Channel number and value of first fault
HIGH INTRSTAGE PRESS ** 20 character label associated with the first fault
10 -19 -1998 9 :46 AM ** Date and time of the first fault
* If a view process screen line is not pro-
grammed in the controller, the line will
be blank.
** These lines will be blank when there are
no faults.
