B.5.5 LOCKING DEVICE FOR TURNING STABILIZER LEGS
Their purpose is to lock the rotation of the stabilizer legs in working and transport position.
LOCKING DEVICE WITH LEVER FOR MANUAL TURNING STABILIZERS
LOCKING DEVICE WITH LEVER FOR AUTOMATIC TURNING STABILIZERS
Failure to lock the stabilizer legs correctly when transporting the machine may cause damage
to property and injury to people.
Rotating lever
Locking pin
Pin guide
locked position
Rotating lever
Locking pin
Pin guide
unlocked position
