USER MANUAL
817NG
TECHNICAL SHEET
D.3
7845282-06 03/20
subject to change without notice
D.2 WINCH SETTINGS
TI1 - SINGLE LINE PULL
Versions 1S 2S 3S 4S 5S
Max line pull kg 1000 1000 1000 1000 1000
TI1 - DOUBLE LINE PULL
Versions
1S
2S
3S
4S
5S
Max line pull kg 1000 1000 1000 1000 1000
TI2 - SINGLE LINE PULL
Versions
1S
2S
3S
4S
5S
Max line pull kg 2000 2000 2000 2000 2000 (*)
Start angle - pull%
Final angle - pull%
- - - -
65°-100%
75°-60%
N/A: configuration not available
(*): configuration requiring pull derating: available only for CE/TOP cranes (PCS)
Pull%: pull derating percentage
When the crane is equipped with winch, the max. working pressure and the limiter setting
pressure are increased by 10 bar with respect to the standard ones.
D.3 TOTAL WEIGHTS
The table shows the total weights including oil inside the cylinders (fully retracted) and considering
oil tank empty.
kg Crane version
Type of stabilizers 1S 2S 3S 4S 5S
ST-M
1775
1910
2025
2130
2220
EX-M 1865 2000 2115 2220 2310
EX-H
1900 2035 2150 2255 2345
SE-H 1935 2070 2185 2290 2380
Additional weight for TI1 winch: 95 kg
Additional weight for TI2 winch: 150 kg
Additional weight of 1st extra function activated with slides: 8 kg pro hydraulic extension
Additional weight of 2nd extra function activated with slides: 2 kg pro hydraulic extension
Additional weight of 1st extra function activated with hose reel: 20 kg
Additional weight of 2nd extra function activated with hose reel: 10 kg
The weights may vary by ±3%
