USER MANUAL
817NG
USE
to change without notice
B.7.5 HOW TO ROTATE DOWNWARDS THE MANUAL TURNING STABILIZER
LEGS
LOCKING DEVICE OF TURNING LEGS
Locking device with lever
Lever 1 perpendicular to extension axis (down): the locking device is engaged
Lever 1 parallel to extension axis (up): the locking device is disengaged
Execute the following procedure:
1) Grasp the handle and turn counter-clockwise the lever (the locking device is disengaged). If the
lever is locked, shake lightly the leg till the lever can be easily operated.
