USER MANUAL
817NG
USE
to change without notice
CLOGGING INDICATOR
The CE tank filter and the high pressure filter (option) have clogging indicators that indicate when
the filter cartridge has to be replaced (pressure gauge on red).
RDC-cranes are always equipped with high pressure filter and clogging indicators.
B.6.2 LOAD INDICATORS
SIGNAL LIGHT TOWER (STANDARD FOR CE/RDC CRANES)
The signal tower provides visual and audible warning signals to indicate the load level of crane:
• Flashing green light, no audible signal: 90% of lifting capacity is not reached
• Fixed orange light, intermittent audible signal: 90% of lifting capacity is reached
• Fixed red light, continuous audible signal: 100% of lifting capacity is reached
3XL/4XL DASHBOARDS
See UM for the stability control system installed.
