Amco Veba 817NG - Overall Dimensions

USER MANUAL
817NG
TECHNICAL SHEET
D.4
7845282-06 03/20
subject to change without notice
D.4 OVERALL DIMENSIONS
FIXED STABILIZERS LEGS
2490
2295
Ø 180
2290
2470
160
80
20°
6625 SE
5425 EX
4225 ST
682 max 673
min 618
EXTRA FUNCTION
305
175
106
W
W+
EXTRA FUNCTION
max 823
min 768
682
97
LONG
1S
2S
3S
4S
5S
W (mm)
825
825
825
825
905
W+ (mm)
940 (*)
940 (*)
940 (*)
940 (*)
985 (**)
(*) activations with slides
(**) activations with hose reel
TURNING STABILIZERS LEGS
2492
Ø 180
20°
160
2535
2545 SE
2312
2332 EX
4252 ST
5452 EX
6648 SE
175
180°
791
736 SE
575
941
886 SE
575
LONG
281
