USER MANUAL
817NG
USE
to change without notice
B.7.14 HOW TO FOLD THE AUTOMATIC TURNING STABILIZERS
LOCKING DEVICES OF STABILIZER EXTENSIONS
Automatic lock of stab. extension
Locking device of stab. leg
The stabilizers can be closed exclusively after the booms are folded in transport position.
Always use the controls on the side on which you are operating the crane.
Perform the following procedure on the control valve side:
1) Lift the stabilizer leg off the ground without fully retracting the rod.
