Ametek EM TEST compact NX User Manual

AMETEK CTS Quick start guide - Conducted
1.00 28 / 50
7.4. 4. Control elements
7.5. 5. Home screen
7.6. 6. Quick start
1. Phenomenon
2. Advanced Menu
3. Brings you back to the Home Screen
4. Test and Control Buttons
5. Output and coupling options
1. Each phenomenon is color coded.
Tap to select.
1. Tapping QUICK START will enable
you to start a test
2. Pressing either “BACK” or ← on the
screen will take you one menu level back.
3. Pressing “TEST ON” at any time will
both enable high voltage pulses as well
as provide power to the EUT and enable
pulses to be generated.
